• Summus praecisio integrata compago iuncta firmitatem motus accurationis diu-term efficit
• Cochleas pilae praecisione importata utitur ad motum accurate et quietam operationem praestandam
• Features servo motore clauso-loop control; minima resolutio 0,002mm, celeritas maxima 800mm/s, et iterabilitas ± 0.025mm
• catenis chalybis immaculatis instructus 3mm/5mm featuring fibulas extensas; onus facultatem ad 10kg
• Protective design for track vincula ne tenaces contagione
• libitum una-segmentum vel dual-segmentum vestigia variae exolvuntur tempore (CT) requisita
• Track profiles pluma dura-anodized metam ad vetustatem superiorem
• User-amica interface; simplex est operari et facile discere
• subsidia Sinica / Anglica diversa lingua in occursum commutatione necessitates
• Pluma-dives; subsidia clausa-loop vigilantia varii processus parametri
• Supports online and offline programming to suit different on-site operational needs
• Expandable includendi MES productionem traceability systems
• subsidia CCD-fundatur fiducialis signum positioning ut efficiens accurate et productio stabilitatem
• Software-fundatur automatic visio ultricies efficaciter tollit situm errorum per tabulas misalignment
• CCD programmatio sustinet, signanter minuendo tempus sumptibus cum doctrina manuali coniungitur
| Basic Parameters | AC-500D |
| Potestas | 220V, 2.2kW, 10A, 50/60 Hz |
| Air Impetus | 80 psi (5.5 bar) |
| Dimensiones | 1194×1462×1610mm (W×D×H) |
| Apparatus Pondus | 700kg |
| Exhaurire Requirements | Diameter 200mm, Airflow ≥13m³/min |
| Width De revolutionibus Ratio | Electric |
| Communication Protocol | SMEMA |
| dispensatio Area | L750×W600mm (Single Valve) |
| L650×W600mm (V-5000 + V-420) | |
| L650×W550mm (V-5000 Tilt + V-420) | |
| X/Y-axis celeritate | 800mm/s |
| X/Y-axis max. acceleratio | 0.8g |
| X/Y/Z-axis repeatability | ± 25μm, 3σ |
| X / Y / Z-axis coegi ratio | Servo motore pila stupra |
| Z-axis celeritas | 300mm/s |
| Z-axis max. acceleratio | 0.3g |
| Deveyor onus facultatem | 10 kg |
| Min. tabula latitudine | 50mm |
| Maximilianus. tabula latitudine | 650mm |
| Maximilianus. tabula longitudo | 700mm |
| Min. tabula ore alvi | 5mm |
| Maximilianus. pars altitudinis | 100mm superius et inferius superficiem TRADUCTOR |
| Altitudo TRADUCTOR | 900±20mm |
| Celeritas TRADUCTOR | 2-5m/min |
| Deportatio directionis | Sinistro → Ius, ius → left |
| Imo reditus semita altitudinis | 500mm iustae ab invehendo semita |
