• Summus subtilis compages compages integratur;
• Importati sunt cochleae pilae praecisio-gradus;
• Clausa servo control ratio;
• Maxima velocitas operating DC mm/s; iteratio ± 25 µm.
• fulcra aucti profile ferro catenis immaculata instructa;
• Varias figurationes TRADUCTOR adiuvat, ut systemata simplicia et duplicata.
• User-amica interface id discere et operari facile est;
• Switchable Chinese/English interface;
Expandable • MES integratio.
• Mark cognitio munus efficit ut motus semita corrigatur secundum vices in Mark positionibus;
• programmatio intuitiva munus celeritatum faciliorem reddit.
• Laser altitudo sentiendi moduli in altitudine dispensans consistentem efficit;
• Dispensans pondus vigilantia ratio pervestigat stabilitatem dispensandi;
• Acus systematis calibrationis sponte acum offset corrigit.
| Basic Parameters | AC-500HC |
| Potestas Supple | 220V 50/60Hz 2.5KW |
| Air Impetus | 80psi (5.5bar) |
| Dimensiones | 990*1300*1630mm (W*D*H) |
| Pondus | 600kg |
| Exhaurire Requirements | Diameter 200mm; Airflow >13m³/min |
| Communication Protocol | SMEMA |
| dispensatio Area | 450* 450* 100mm (Single Valve) |
| Certification signa | CE/UL |
| Motus Type | Servo Motor + Ball Screw |
| X-axis Travel | 460mm |
| Y-axis Travel | 550mm |
| Z-axis Travel | 100mm |
| X/Y-axis celeritate | 600mm/s |
| X/Y-axis accelerationis | 0.8g |
| Z-axis celeritas | 300mm/s |
| Z-axis accelerationis | 0.3g |
| X/Y/Z-axis repeatability | ± 25μm @ 3σ |
| Imperium modum | Industriae PC + Motus control card |
| Altitudo TRADUCTOR | 870-950mm |
| Celeritas TRADUCTOR | 400mm/s |
| Latitudo temperatio modum | Lorem width temperatio |
| Latitudo range | 40-500mm |
| Minimam tabulam in ore latitudo | 3mm |
| Rail productum longitudinem facultatem | 800mm (Single-section) |
| Rail onus facultatem | 10kg |
| Tabula alvi altitudo | Top 100mm / Bottom 100mm |
