• Summus praecisio integrata compago iuncta firmitatem motus accurationis diu-term efficit
• Cochleas pilae praecisione importata utitur ad motum accurate et quietam operationem praestandam
• Features servo motore clauso-loop control; minima resolutio 0,002mm, celeritatis maximae usque ad 1000mm/s, et iterabilitas ± 0.025mm
• catenis chalybis immaculatis instructus 3mm/5mm featuring fibulas extensas; onus facultatem ad 10kg
• Protective design for track vincula ne tenaces contagione
• libitum unius segmenti vel dual-segmenti vestigia ad varias Cycle Tempus (CT) iudicium
• Track profiles pluma dura-anodized metam ad vetustatem superiorem
• User-amica interface; simplex est operari et facile discere
• subsidia Sinica / Anglica diversa lingua in occursum commutatione necessitates
• Pluma-dives; subsidia clausa-loop vigilantia varii processus parametri
• Supports online and offline programming to suit different on-site operational needs
• Expandable includendi MES productionem traceability systems
• subsidia CCD-fundatur fiducialis signum positioning ut efficiens accurate et productio stabilitatem
• Software-fundatur automatic visio ultricies efficaciter tollit situm errorum per tabulas misalignment
• programmationem CCD adiuvat, signanter minuendo tempus et laboris impensas cum doctrina manuali coniuncta.
| Basic Parameters | AC-600D |
| Potestas Supple | 220V 50/60Hz 2.5KW |
| Air Impetus | 80psi (5.5bar) |
| Dimensiones | 1290*1480*1720mm (W*D*H) |
| Pondus | 900kg |
| Exhaurire Requirements | Diameter 200mm; Airflow >13m³/min |
| Communication Protocol | SMEMA |
| dispensatio Area | L650 x W450mm (Single Valve) |
| L560 x W450mm (V-5000 + V-420) | |
| L560 x W380mm (V-5000 Tilt + V-420) | |
| Certification signa | CE/UL |
| Coegi Ratio | Servo motor + pila cochlea |
| X-axis Travel | 760mm |
| Y-axis Travel | 640mm |
| Z-axis Travel | 100mm |
| X/Y-axis Volo | 1000mm/s |
| X/Y-axis Acceleratio | 0.8g |
| Z-axis Volo | 300mm/s |
| Z-axis Acceleratio | 0.3g |
| X/Y/Z-axis Repeatability | ± 25μm @ 3σ |
| Imperium Methodo | Industriae PC + motus imperium card |
| Altitudo TRADUCTOR | 870–950mm |
| TRADUCTOR Mobilitate | 400mm/s |
| Width De revolutionibus Ratio | Lorem width temperatio |
| Latitudo dolor | 40-500 mm |
| Minimam tabulam in ore latitudo | 3 mm |
| Rail productum facultatem longitudinem | 1200 mm (sectio singularis) / 450 mm (sectio duarum) |
| Rail onus facultatem | 10 kg |
| Tabula alvi altitudo | Top: 100 mm / Bottom: 100 mm |
