Secures X, Y, Z utuntur servo motorum et pila cochleae impellit, stabilis et durabilis structura procurans; axis R-axis coordinate cum axibus X, Y, Z operari potest, ut per trajectorias spatiales dispensare possit.
• Capacitor subsidii
• piscinam habitationi cione
• Inductor coil supplementi
• Nullam compagem
| Basic Parameters | RS-400 | RS-500 | RS-400H |
| Dimensiones W×D×H (mm) | 640×750×811.5 | 806×941×902.5 | 640×746×812 |
| X/Y/Z Axis Travel (mm) | 400×400×100 | 500×500×100 | 400×400×100 |
| Equipment Weight (kg) | 105 | 122 | 106 |
| R-axis gyrationis angulus (°) | 0-360 | 0-360 | |
| R-axis repeatability (mm) | ± 0.02 | ± 0.01 | |
| R-axis maximam celeritatem gyrationis (°/sec) | 360 | 720 | |
| X/Y/Z repeatability (mm) | ± 0.01 | ± 0.01 | |
| X / Y / Z celeritate maxima (mm/s) | 800/800/300 | 800/800/300 | |
| X / Y / Z accelerationis | 0.4g | 0.4g | |
| X/Y/Z mechanica compages | H-Bridge | H-Bridge | |
| Imperium modum | Motus Standalone controller | Motus Standalone controller | |
| X / Y / Z coegi modum | AC servo + summus praecisio moduli | AC servo + summus praecisio moduli | |
| R-axis coegi modum | Stepper motor + reducer | Servo motor + summus praecisio reducer | |
| R-axis onus (kg) | 2 | 3 | |
| Y-axis onus mensa (kg) | 10 | 10 | |
| Modus programmandi | Programmator handheld | Programmator handheld | |
| Repono facultatem (MB) | 128 | 128 | |
| Potentia (W) | 700 | 800 | |
